Bandsaw Machine RF-1018R RongFu

The RF-1018R RongFu Bandsaw Machine, a robust and versatile tool designed for precise cutting tasks. This machine offers reliability and efficiency, making it a perfect fit for workshops of all sizes. Large sized workshop step pulley bandsaw with swivel base & upgrade options for cutting various types of pipe & bar efficiently.

Categories: , , ,

Description

10” X 18″ Metal Bandsaw RF-1018R

With its advanced features and sturdy construction, the RF-1018R ensures smooth operation and high-quality results when cutting various materials. Ideal for professionals and hobbyists alike seeking superior performance in their cutting operations.

RF-1018R (2)

Cutting Capacity

Choose the right bandsaw for your needs based on its cutting capacity.

Cutting Capacity RF-1018R

Features

RF-1018R

Work Table Swivel for Angle Cutting Saves Machine Space.
T-Slot Design Swivel Base for Stability.
Cast Blade Wheels for Strength & Durability.
Heavy Duty 4 Step Pulley Gearbox.
Hydraulic Brake Down Feed Dial on Control Panel.
Large Setting Scale for Counter Blade Position Setting.
Carbide Guide with Bearing fr Stability and Durability.
Tru-lock Vise Provides Firm Clamping.
Adjustable Blade Guide Arm Increases Work Piece Precision & Saw Blade Life.
Clamping Vise for 0º – 45º Angle Cutting.
Coolant System for Wet Cutting.
Wide Chip Tray with Filter Net for Easy Chip Handling.

RF-1018RV

Heavy Duty Variable Speed.

RF-1018RVAA

Semi Auto Bow.
Hydraulic Vise.

Table Specifications

ItemRF-1018RRF-1018RVRF-1018RVAA
Main Motor HP2 (1.5kw)(3-phase)2 (1.5kw)(3-phase)2 (1.5kw)(3-phase)
Speed MT/min60HZ / 30-60-88-11560HZ / 30~11060HZ / 30~110
Speed Ft/min60HZ /114-196-288-37760HZ / 98~36060HZ / 98~360
Saw Blade mm (WxTxL)27×0.9×309027×0.9×309027×0.9×3090
Saw Blade inch (WxTxL)1.06×0.045×121.661.06×0.045×121.661.06×0.045×121.66
Machine Dimensions mm (LxWxH)1800x820x12802075x820x12802075x820x1280
Machine Dimensions inch (LxWxH)70.9×32.3×50.481.7×32.3×50.481.7×32.3×50.4
Packing Dimensions mm (LxWxH)1730x830x11601730x830x11601730x830x1160
Packing Dimensions inch (LxWxH)68.1×32.7×45.768.1×32.7×45.768.1×32.7×45.7
Machine Weight NW/GW390/430 kgs
860/945 lbs		390/430 kgs
860/945 lbs		420/470 kgs
925/1035 lbs
No.of Machines
Packed in 20″ container		7 sets / SKD 14 sets7 sets / SKD 14 sets7 sets / SKD 14 sets
No.of Machines
Packed in 40″ container		14 sets/ SKD 28 sets14 sets/ SKD 28 sets14 sets/ SKD 28 sets
